Name: Aluminum Anodes
Brand: WEITONG MARINE
SKU: 03485
Availability: InStock
Rating: 5 (1 reviews)

Home > IMPA Marine Material > 67 - Metal Sheets,Bars,et...

Description

Aluminum Anodes

Product Features：

·Light weight, excellent electrochemical performance, low driving voltage, high current efficiency; environmentally friendly, uniform dissolution and long service life.

Application Scope:

·Suitable for ships, port engineering facilities, submarine pipelines, offshore wind power platforms, etc. in seawater medium;

·Transmission pipelines, underground fresh water pipelines, chemical storage tanks, etc. in brackish water medium.

·It is also applicable to scenarios requiring cathodic protection and having environmental protection requirements.

Common Specifications and Models：

Model	Specifications/mm	Weight/kg
Model	L × W × H	Weight/kg
AH-1	800×140×60	17
AH-2	800×140×50	15
AH-3	800×140×40	12
AH-4	600×120×50	10
AH-5	400×120×50	6.5
AH-6	500×100×40	5.5
AH-7	400×100×40	4.5
AH-8	300×100×40	3.5
AH-9	250×100×40	2.5
AH-10	180×70×35	1.2
AH-11	300×150×50Double Iron Feet	5.8
AH-12	300×150×40Double Iron Feet	4.6
AH-13	300×150×50 Bolt-Type	5.8
AH-14	300×150×40 Bolt-Type	4.8
