Marine Mooring Equipment

Weitong Marine is a one of the main suppliers of marine mooring equipments: rubber fende,ship launching airbag, anchor, anchor chain, anchor stopper, marine bollard, fairleads,fairlead roller, mooring ropes, mooring reels, marine towing hook, marine chock,pamana chock.
Certificates ABS, DNV,GL,NK,BV,RINA,RMRS,CCS,BKI are available for these items.

Product Description

Type A/B/C Marine Mooring Chock Boat Closed Fairlead Chock Ship Panama Chock

Mooring Chock A Type CB34-76 can guide the rope from the inboard to the outboard at certain direction, change the trend of rope and limit its place. It can reduce the abrasion between rope with gunwale, avoid increasing the stress due to a sharp bend. Closed Chock is Widely used for small boats,ships,tug,cargo vessel,tankers etc. We can manufactures chocks in a wide variety of sizes and styles,also can customized the chock according to your drawing.
Mooring Chock A Type CB34-76 Type C,Type B,Type C and Type D are available as well.

Weitong Marine provide Kinds of Marine Chocks as following:

1.(DIN81915) Type Din Chocks,
2.Type U.S.Panama Chock,
3.JIS F2005-1975 Closed Chocks,
4.JISF 2007-1976 Mooring Chock(A),
5.JISF2017-1982 Panama Chock(AC),JISF2017-1982 Panama Chock(BC)
6.JISF2030-1978 Single Point Mooring Pipes(A),JISF2030-1978 Single Point Mooring Pipes(B)

Specification:

JIS F2005-75 Closed Chock can guide the rope from the inboard to the outboard at certain direction, change the trend of rope and limit its place. It can reduce the abrasion between rope with gunwale, avoid increasing the stress due to a sharp bend. Closed Chock is Widely used for small boats,ships,tug,cargo vessel,tankers etc. We can manufactures chocks in a wide variety of sizes and styles,also can customized the chock according to your drawing.

Specification:
DIN81915 Bulwark Mounted Chock (Type A)

Application: used for vessel, tug, cargo ship, industrial ships etc., usually it is installed at two sides of
tankers for general mooring purposes
SWL: 20KN to 320KN
Finishing: one layer of shop primer after sandblasting 2.5
Installation site: on the bulwark

DIN81915 Bulwark Mounted Panama Chock (Type A)
Model	SWL	Dimensions(mm)						Weight (kg)
Model	(kN)	L	W	H	H1	A	B	Weight (kg)
A2	20	360	200	315	70	160	115	26
A3	30	450	250	390	75	200	140	42
A5	50	550	300	480	80	250	180	74
A8	80	680	360	585	90	320	225	120
A12	125	840	440	710	110	400	270	185
A20	200	1020	520	840	130	500	320	285
A32	320	1300	700	1100	150	600	400	795

DIN81915 Deck Mounted Panama Chock (Type C )

Application: used for vessel, tug, cargo ship,industrial ships etc, usually it is installed at two sides of
tankers for general mooring purposes.
SWL: 20KN to 320KN
Finishing: one layer of shop primer after sandblasting 2.5
Installation site: on the deck

Model	SWL	Dimensions(mm)						Weight (kg)
Model	(kN)	L	W	H	H1	A	B	Weight (kg)
C2	20	360	200	316	158	160	115	29
C3	30	450	250	390	195	200	140	48
C5	50	550	300	480	240	250	180	85
C8	80	680	360	586	293	320	225	136
C12	125	840	440	710	355	400	270	211
C20	200	1020	520	840	420	500	320	325
C32	320	1300	700	1100	550	600	400	840
